JS-3 THIC - Frame (Carbon & Hardware Only) HDZero Compatible
JS-3 THIC - Frame (Carbon & Hardware Only) HDZero Compatible
Couldn't load pickup availability
Note: TPU parts not included. They can be purchased separately in the Spares Section or STLs downloaded here for 25mm Standoff Version or download here for the 20mm Standoff Version
Note: This is only the carbon & hardware for the frame. For proper assembly, additional TPU parts are required to complete the build. We have printing on demand available, but additionally all the parts are available on thingiverse as a free STL download.
TPU sold through BMS Racing is made for the TBS Triumph Pro U.FL, Foxeer Predator Nano & HDZero Version. If you are using a different antenna, camera or lens, please contact us first to verify compatibility before you make a purchase. We will be producing more mounts & variants as required.
Kit Includes:
Everything needed to build the frame, less the TPU Parts and Electronics.
So Battery Pad, Battery Strap is included in the kit.
Recommended parts list (HDZero):
VTX Antenna: TBS Triumph pro (U.Fl for standard TPU)
VTX: HDZero Race V3 or Foxeer HDZero VTX
Camera: HDZero 90FPS Cam with lens upgrade
FC: Foxeer F7 or H7 FC 20x20 (note if 10v bec required)
ESC: Foxeer Reaper 60A Slim
Propeller: Gemfan 51366 V3, Gemfan 5127, Gemfan 51466 V2 or HQProp BMS
Motor: T-Motor BMS Raptor V2, T-Motor F50 2150KV, VCI 2207 2100KV
Battery: Tattu R-Line V5 1400, 1550
RX: TBS Tracer, TBS Crossfire or Radiomaster ELRS
Recommended parts list (Analog):
VTX Antenna: TBS Triumph pro (U.Fl for standard TPU)
VTX: TBS Unify Pro (32 nano or nano)
Camera: Predator nano
FC: Foxeer F7 or H7 FC 20x20
ESC: Foxeer Reaper 60A Slim
Propeller: Gemfan 51366 V3, Gemfan 5127, Gemfan 51466 V2 or HQProp BMS
Motor: T-Motor BMS Raptor V2, T-Motor F50 2150KV, VCI 2207 2100KV
Battery: Tattu R-Line V5 1400, 1550
RX: TBS Tracer, TBS Crossfire or Radiomaster ELRS
Tune will be available as a preset soon, but for now just contact Thomas Bitmatta (@bmsthomas_ on instagram)
JS-3 THIC Build Diagram
